MD200S0.75B-INT
Un=220 VAC, In=4.6 A, P=0.75 kW, Modbus RTU, size A, 485 + 1xI/O
Software:
Dati tecnici
Specifiche
| Size |
Size A |
| Control method |
Open Loop V/F Open Loop Vector Control |
| Axes Control |
Single-Axis |
| Rated Voltage [V] |
220 V single phase |
| Communication |
Modbus RTU |
| Rated Output Current |
4,6 A |
| Power (HD) |
0.75 kW |
| Overload capacity |
150% (60 s) - 180% (3 s) |
| Max output frequency |
500 Hz |
| Built-in braking unit |
V |
| IP |
IP20 |
| Weight |
1.3 kg |
| Internal EMC Filter |
Category C3 |
| Appropriate External EMC filter (C2) |
FN 2090-12-08 |
| Dimensions H x W x D |
180x75x145 mm |
Accessori
MDKE9
Remote LCD text indicator for MD200, MD290, , MD310, MD500, MD500-PLUS, MD520, CS710, for parameter programming, parameter copy and backup, USB gateway, works with standard RJ45 cable (MDCAB 3.0m inluded)
CP600-BASE1
MDKE9 keypad installation base on the cabinet door
MDPCKIT02
AC drive PC communication kit, connects to MD200/290/310/500/380/380L/IS580 via RJ45
MDKE8
Remote LED keypad for MD200, for parameter programming and monitoring,
potentiometer for speed control, works with standard RJ45 cable (MDCAB 3.0m inluded)
